产品名称: | ZM86(110V-800V)开关放电管 | |||||
型号规格: | |
|||||
产品类别: | 常规产品 -- 电子电器 -- 放电管 | |||||
参考价格: | 厂价直销 | |||||
产品品牌: | 正茂 | |||||
产品产地: | 上海 | |||||
可供数量: | 批量 | |||||
供货周期: | 现货(或电询) | |||||
|
||||||
产品简介: |
|
Type(Ф8×6mm) |
ZM86 |
ZM86 150L |
ZM86 |
ZM86 |
ZM86 |
ZM86 |
ZM86 |
ZM86 |
ZM86 |
ZM86 600L- |
ZM86 |
ZM86 | |
DC Spark-over voltage (v) and tolerance |
82~138 |
150±20% |
230±16% |
250±15% |
300±15% |
350±15% |
400±15% |
450±15% |
500±15% |
550±15% |
600±15% |
680~900 | |
Insulation resistance at 100v DC (Ω) |
50V DC |
≥109 |
≥109 |
≥109 |
≥109 |
≥109 |
≥109 |
≥109 |
≥109 |
≥109 |
≥109 |
≥109 | |
Capacitance (PF) |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 |
<1.5 | |
Switching frequency(HZ) |
600 |
500 |
300 |
270 |
220 |
180 |
150 |
120 |
200 |
180 |
150 |
100 | |
Number of on-off (ten thousand times) |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 |
40 | |
Peak current(A) |
120 |
180 |
270 |
290 |
340 |
410 |
480 |
540 |
270 |
320 |
360 |
530 | |
Operation and storage temperature (℃) |
-20~ |
-20~ +130 |
-20~ |
-20~ |
-40~ |
-40~ |
-40~ |
-40~ |
-40~ |
-40~ +130 |
-40~ |
-40~ | |
Weight(g) |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
~1.5 |
