YL(J599G Fiber optic cable) circular electrical connectorDetailed product description：

Main features of YL (J599G fiber optic cable) circular electrical connector

The connector interface size complies with GJB 599A (MIL-DTL-38999 III)
The total length and branch length of the optical cable can be adjusted according to customer requirements
Five key positioning, with blind insertion and anti misoperation functions
Can meet RoHS requirements
Support photoelectric mixed loading

Main technical specifications of YL (J599G fiber optic cable) circular electrical connector:

Insertion loss: Head socket mutual matching, insertion loss IL ≤ 0.6dB (4-core), ≤ 0.75dB (6-core).
Mechanical lifespan: 500 cycles
Vibration: 10Hz~500Hz, acceleration 98m/s2
Impact: 980m/s2
Working temperature: -40~80 ℃
Tensile strength: ≥ 300N (main cable)
Has resistance to high-intensity vibration characteristics
Damp heat: temperature (+30 ± 2) ℃~(+60 ± 2) ℃, humidity 90%~95%, duration 4d
Salt spray: 5% NaCl salt spray for 48 hours, no corrosion on metal parts
