Range

Any range within 0-3.5MPa, with a minimum range of 5kPa

Accurately determine the level

Level 0.2
Level 0.5

medium temperature

－ 30℃～85℃

Ambient temperature

－ 20℃～85℃

power supply voltage

DC 24V (12V～32V)

load capacity

Current output type ≤ 500 Ω; Voltage output type: ≥ 3k Ω

nonlinear

0.2％F•S

Delay and repeatability

0.1％F•S

long-term stability

0.1％F•S/y

Thermal zero drift

0.02％F•S/℃

response time

≤ 50ms

Maximum work pressure

2 times the range

electrical connection

Hosman connector/terminal block

process connection

M24 × 1.5 external thread or clamp type quick connect flange

measuring medium

Compatible with 316L stainless steel medium

Material of external components

Ordinary stainless steel/316L stainless steel

Protection level

IP65 (P-type)/IP 54 (H-type)
