LGA0410色环电感器电气特性参数

品名

电感量

(uH)

品质因素

(MIN)

测试频率

(MHz)

自共振频率(MHz)MIN

直流电阻(OHM)MAX

额定电流

(mA)MAX

LGA0410-1R0K

1.0

50

25.2

157

0.09

920

LGA0410-1R2K

1.2

50

7.96

144

0.10

880

LGA0410-1R5K

1.5

55

7.96

131

0.23

830

LGA0410-1R8K

1.8

60

7.96

121

0.25

790

LGA0410-2R2K

2.2

80

7.96

110

0.28

750

LGA0410-2R7K

2.7

85

7.96

100

0.30

720

LGA0410-3R3K

3.3

90

7.96

94

0.34

670

LGA0410-3R9K

3.9

90

7.96

86

0.37

640

LGA0410-4R7K

4.7

90

7.96

80

0.39

620

LGA0410-5R6K

5.6

80

7.96

74

0.43

590

LGA0410-6R8K

6.8

80

7.96

58

0.48

550

LGA0410-8R2K

8.2

85

7.96

53

0.52

530

LGA0410-100K

10

85

7.96

45

0.58

500

LGA0410-120K

12

75

2.52

30

0.63

480

LGA0410-150K

15

75

2.52

20

0.72

460

LGA0410-180K

18

70

2.52

14

0.77

430

LGA0410-220K

22

65

2.52

7.9

0.84

410

LGA0410-270K

27

65

2.52

7.6

0.94

390

LGA0410-330K

33

55

2.52

6.3

1.03

370

LGA0410-390K

39

55

2.52

6.3

1.12

350

LGA0410-470K

47

45

2.52

6.3

1.22

340

LGA0410-560K

56

45

2.52

6.2

1.34

320

LGA0410-680K

68

40

2.52

5.7

1.47

305

LGA0410-820K

82

35

2.52

5.3

1.62

290

LGA0410-101K

100

30

2.52

4.8

1.80

275

LGA0410-121K

120

70

0.796

3.8

3.70

185

LGA0410-151K

150

80

0.796

3.5

4.20

175

LGA0410-181K

180

80

0.796

3.3

4.60

165

LGA0410-221K

220

70

0.796

3.0

5.10

155

LGA0410-271K

270

70

0.796

2.8

5.80

145

LGA0410-331K

330

65

0.796

2.6

6.40

137

LGA0410-391K

390

65

0.796

2.4

7.00

133

LGA0410-471K

470

60

0.796

2.25

7.70

126

LGA0410-561K

560

60

0.796

2.1

8.50

120

LGA0410-681K

680

55

0.796

1.95

9.40

113

LGA0410-821K

820

55

0.796

1.85

12.0

100

LGA0410-102K

1000

50

0.252

1.40

17.0

100

P/N 料号

A  (MAX)

B (MAX)

C (MAX)

LGA0204

2.8

4.0

0.5±0.1

LGA0307

3.0

7.62

0.5±0.1

LGA0410

4.0

10.5

0.6±0.1

LGA0510

5.0

12.0

0.6±0.1
